型號 | 匹數 | 壓縮機 | 蒸發(fā)-40℃ | 蒸發(fā)-35℃ | 蒸發(fā)-30℃ | 蒸發(fā)-25℃ | 外形尺寸 | |||||||
型號 | 數量 | 制冷量 | 輸入 | 制冷量 | 輸入 | 制冷量 | 輸入 | 制冷量 | 輸入 | 長 | 寬 | 高 | ||
JX2150XL | 150 | HSN7471-75 | 2 | 91.26 | 85.40 | 120.00 | 91.40 | 152.00 | 98.00 | 187.90 | 105.40 | 2800 | 1750 | 2100 |
JX3210XL | 210 | HSN7461-70 | 3 | 120.84 | 112.80 | 158.00 | 120.60 | 200.10 | 129.30 | 247.20 | 139.20 | 3400 | 1750 | 2100 |
JX3225XL | 225 | HSN7471-75 | 3 | 136.95 | 128.10 | 179.80 | 137.10 | 228.00 | 147.00 | 280.90 | 158.10 | 3400 | 1750 | 2100 |
JX4280XL | 280 | HSN7461-70 | 4 | 160.88 | 150.40 | 210.60 | 160.80 | 266.64 | 172.40 | 329.60 | 185.60 | 4300 | 1750 | 2400 |
JX4300XL | 300 | HSN7471-75 | 4 | 182.36 | 170.80 | 239.80 | 182.80 | 303.00 | 196.00 | 376.00 | 210.80 | 4300 | 1750 | 2400 |
JX5350XL | 350 | HSN7461-70 | 5 | 201.60 | 188.00 | 263.30 | 201.00 | 331.60 | 215.50 | 412.50 | 232.50 | 5200 | 2000 | 2400 |
JX5375XL | 375 | HSN7471-75 | 5 | 228.40 | 213.50 | 299.45 | 228.50 | 378.80 | 245.00 | 469.00 | 263.50 | 5200 | 2000 | 2400 |
JX6420XL | 420 | HSN7461-70 | 6 | 241.60 | 225.60 | 215.80 | 241.20 | 400.26 | 258.60 | 495.20 | 278.40 | 6100 | 2000 | 2400 |
JX6450XL | 450 | HSN7471-75 | 6 | 274.00 | 256.20 | 359.00 | 274.20 | 454.38 | 294.00 | 561.80 | 316.20 | 6100 | 2000 | 2400 |
型號 | 匹數 | 壓縮機數量 | 機組對外管路尺寸 | 機組對外管路尺寸 | 電氣參數 | 房間通風量 | |||||
排氣 | 吸氣 | 供液 | 排氣 | 吸氣 | 供液 | 最大工作電流A | 保險絲電流A | ||||
JX2150XL | 150 | 2 | DN50 | DN100 | 28 | 1 | 2 | 2 | 311 | 326 | 9800 |
JX3210XL | 210 | 3 | DN65 | DN125 | 35 | 1 | 2 | 2 | 386 | 401 | 14000 |
JX3225XL | 225 | 3 | DN65 | DN125 | 35 | 1 | 2 | 2 | 415 | 430 | 14700 |
JX4280XL | 280 | 4 | DN65 | DN125 | 35 | 1 | 3 | 3 | 482 | 497 | 18700 |
JX4300XL | 300 | 4 | DN65 | DN125 | 35 | 1 | 3 | 3 | 519 | 534 | 19600 |
JX5350XL | 350 | 5 | DN80 | DN100 | 35 | 1 | 4 | 4 | 578 | 593 | 23400 |
JX5375XL | 375 | 5 | DN80 | DN125 | 35 | 1 | 4 | 4 | 623 | 638 | 24500 |
JX6420XL | 420 | 6 | DN80 | DN125 | 35 | 1 | 4 | 4 | 675 | 690 | 28000 |
JX6450XL | 450 | 6 | DN80 | DN125 | 35 | 1 | 4 | 4 | 727 | 742 | 29400 |
